Car Wiring Diagrams for Heated seats circuit for BMW Z4 E85/E86 facelift (2005-2009)

BRN WIRE CENTER CONSOLE SWITCH CENTER COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST HEATING ELEMENT (IN DRIVER'S SEAT BACKREST) DRIVER'S SEAT CUSHION HEATING ELEMENT (IN DRIVER'S SEAT CUSHION) FUSE GRN/VIO WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN START, RUN OR ACC PASSENGER'S SEAT BACKREST HEATING ELEMENT (IN PASSENGER'S SEAT BACKREST) PASSENGER'S SEAT CUSHION HEATING ELEMENT (IN PASSENGER'S SEAT CUSHION) POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE RED/VIO WIRE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED/YEL WIRE
