Electrochromic mirror circuit for BMW Z4 E85/E86 facelift (2005-2009)
Electrochromic mirror circuit
ANTI-THEFT LED
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER'S DOOR MODULE
DRIVER'S SIDE OUTSIDE MIRROR
ELECTRO- CHROMIC ACTIVATION
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS)
FUSE
GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH)
GRN WIRE
GRN/WHT WIRE
GRY/BLK/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
NCA WIRE
PASSENGER'S SIDE OUTSIDE MIRROR
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RED WIRE
RED/GRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
