Back-up lamps circuit for BMW Z4 E85/E86 facelift (2005-2009)
Back-up lamps circuit
BLU WIRE
BRN WIRE
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
FUSE
GRN WIRE
HOT IN RUN OR START
INSTRUMENT CLUSTER CONTROL MODULE
INTEGRATED SUPPLY MODULE (IVM) (LEFT REAR OF ENGINE COMPT)
LEFT BACK-UP LIGHT
LEFT TAIL LIGHT
NAVIGATION SYSTEM
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
REVERSING LIGHT RELAY
REVERSING LIGHT SWITCH (M/T)
RIGHT BACK-UP LIGHT
RIGHT TAIL LIGHT
TRANSMISSION CONTROL UNIT (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
