BMW Z4 E85/E86 facelift (2005-2009) washer pump Wiring diagram
This page shows the only wiring diagram for the component.washer pump, which is found in the car BMW Z4 E85/E86 facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram washer pump (1 of 1)
1 15 TERM 30 GROUND
11 25 LT HEATED WASHER RT HEATED WASHER
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HEAD- LIGHT WASHER PUMP RELAY
HEADLIGHT WASHER PUMP
HOT AT ALL TIMES
HOT IN RUN, ACCY AND
LEFT HEATED WASHER NOZZLE
NCA WIRE
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RAIN/HEADLIGHT SENSOR (TOP CENTER OF WINDSHIELD) (IF EQUIPPED)
RED WIRE
RED/GRY WIRE
RIGHT HEATED WASHER NOZZLE
VIO WIRE
VIO/WHT WIRE
WASHER PUMP
WHT WIRE
WHT/RED/YEL WIRE
WIND- SHIELD WASHER PUMP (RIGHT FRONT ENGINE COMPT)
WIPER MOTOR
WIPER RELAY 1
WIPER RELAY 2
WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit -> WASHER PUMP
