BMW Z4 E85/E86 facelift (2005-2009) passenger's side b-pillar airbag sensor Wiring diagram
This page shows the only wiring diagram for the component.passenger's side b-pillar airbag sensor, which is found in the car BMW Z4 E85/E86 facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side b-pillar airbag sensor (1 of 1)
BATTERY
BATTERY TERMINAL GENERATOR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE (REAR OF CENTER CONSOLE)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
INSTRUMENT CLUSTER CONTROL MODULE
JUMP
K- BUS
NCA WIRE
PASSENGER AIRBAG DEACTIVATION SWITCH
PASSENGER SIDE AIRBAG INFLATOR ASSEMBLY
PASSENGER'S AIRBAG INFLATOR ASSEMBLY
PASSENGER'S SEAT BELT TENSIONER GENERATOR
PASSENGER'S SIDE B-PILLAR AIRBAG SENSOR
PASSENGER'S SIDE FRONT AIRBAG SENSOR
PASSENGER'S SIDE FRONT DOOR AIRBAG SENSOR
RED WIRE
RIGHT FRONT KNEE AIRBAG GENERATOR
SEAT OCCUPANCY RECOGNITION
TERMINAL POINT
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> PASSENGER'S SIDE B-PILLAR AIRBAG SENSOR
