BMW Z4 E85/E86 facelift (2005-2009) interior rear view mirror Wiring diagram
This page shows the only wiring diagram for the component.interior rear view mirror, which is found in the car BMW Z4 E85/E86 facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior rear view mirror (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CIGAR LIGHTER RELAY
CRUISE CONTROL STEERING COLUMN SWITCH
DRIVER'S DOOR MODULE
DYNAMIC STABILITY CONTROL
ELECTROCHROMIC
ELECTRONIC POWER STEERING
ELECTRONIC VEHICLE IMMOBILIZER
FROM
FROM FUSE
FUEL PUMP CONTROL (EKPS)
FUSE
GRN WIRE
HEATING, A/C SYSTEM
IGNITION SWITCH
INTEGRATED SUPPLY MODULE (IVM)
INTERIOR REAR VIEW MIRROR
LIGHT INSTRUMENT SWITCH CLUSTER CLUSTER CONTROL MODULE
NCA WIRE
OBD II SOCKET
OFF
PARK DISTANCE CONTROL UNIT
PASSENGER'S SIDE OUTSIDE MIRROR
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
REAR WINDOW DEFROSTER RELAY
RED WIRE
RUN WIRE
SPORT BUTTON
STEERING ANGLE SENSOR DSC
TERMINAL 15 POWER SAVING RELAY
TO FUSE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> INTERIOR REAR VIEW MIRROR
