BMW Z4 E85/E86 facelift (2005-2009) driver side b-pillar airbag sensor Wiring diagram
This page shows the only wiring diagram for the component.driver side b-pillar airbag sensor, which is found in the car BMW Z4 E85/E86 facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side b-pillar airbag sensor (1 of 1)
AIRBAG INDICATOR LIGHT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CRASH SAFETY MODULE (REAR OF CENTER CONSOLE)
DRIVER SIDE AIRBAG INFLATOR ASSEMBLY
DRIVER SIDE B-PILLAR AIRBAG SENSOR
DRIVER'S AIRBAG INFLATOR ASSEMBLY
DRIVER'S SEAT BELT BUCKLE CONTACT
DRIVER'S SEAT BELT TENSIONER GENERATOR
DRIVER'S SIDE FRONT AIRBAG SENSOR
DRIVER'S SIDE FRONT DOOR AIRBAG SENSOR
FUSE
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
HOT IN ACC, RUN, START
LEFT FRONT KNEE AIRBAG GENERATOR
NCA WIRE
PASSENGER'S SEAT BELT BUCKLE CONTACT
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RED WIRE
RED/WHT WIRE
VIO WIRE
VIO/BLU WIRE
VIO/WHT WIRE
VOLUTE SPRING
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> DRIVER SIDE B-PILLAR AIRBAG SENSOR
