BMW Z4 E85/E86 facelift (2005-2009) cd af- Wiring diagrams
This page contains all the electrical diagrams for the component. cd af-, in which he is found in the car BMW Z4 E85/E86 facelift (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cd af- (1 of 3)
1 2 3 4 5 6 7 8 RR + RF + LF + LR + RR - RF - LF - LR -
ANTENNA
ANTENNA DIVERSITY (LEFT SIDE OF REAR COMPT)
AV SOCKET
AV SOCKET AV SOCKET NAVI + TELE AF+
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRN WIRE
CD AF+ L CD AF+ R
CD AF-
CD CHANGER
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (LEFT FRONT LUGGAGE COMPT)
FM AMPLIFIER
FM ANTENNA
FUSE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN, ACC OR START
K-BUS MUTE TELE ON GROUND ANTENNA LIGHT TERM 30 TERM R
LEFT FRONT WOOFER SPEAKER RIGHT FRONT TWEETER SPEAKER
LEFT REAR MID-RANGE SPEAKER LEFT FRONT TWEETER SPEAKER
LEFT TV ANTENNA
NAVIGATION SYSTEM
NCA WIRE
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RADIO
RADIO NAVI AV SOCKET SH NAVI - TERM 50
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT WOOFER SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RIGHT TV ANTENNA
ROD ANTENNA
TELEPHONE TRANSCEIVER
VIDEO MODULE (REAR CENTER OF REAR COMPT)
VIO/WHT WIRE
VOICE CONTROL SYSTEM
W/ ANTENNA DIVERSITY
W/ VIDEO MODULE W/O VIDEO MODULE
W/ VOICE RECOGNITION SYSTEM
W/O ANTENNA DIVERSITY
W/O VOICE RECOGNITION SYSTEM (LEFT FRONT LUGGAGE COMPT)
WHT BRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Base radio circuit -> CD AF-
Wiring diagram cd af- (2 of 3)
1 2 3 4 5 6 7 8 RR + RF + LF + LR + RR - RF - LF - LR -
ANTENNA
ANTENNA DIVERSITY (LEFT SIDE OF REAR COMPT)
AV SOCKET
AV SOCKET AV SOCKET NAVI + TELE AF+
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
CD AF+ L CD AF+ R
CD AF-
CD CHANGER
COMPUTER DATA LINES SYSTEM
FM AMPLIFIER
FM ANTENNA
GRY/RED WIRE
K-BUS MUTE TELE ON GROUND ANTENNA LIGHT TERM 30 TERM R
LEFT TV ANTENNA RIGHT TV ANTENNA
NAVIGATION SYSTEM
NCA WIRE
RADIO
RADIO NAVI AV SOCKET SH NAVI - TERM 50
RED/BLU WIRE
RED/YEL WIRE
ROD ANTENNA
TELEPHONE TRANSCEIVER
VIDEO MODULE (REAR CENTER OF REAR COMPT)
VIO/WHT WIRE
VOICE CONTROL SYSTEM
W/ ANTENNA DIVERSITY
W/ VIDEO MODULE
W/ VOICE RECOGNITION SYSTEM
W/O ANTENNA DIVERSITY
W/O VIDEO MODULE
W/O VOICE RECOGNITION SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Premium radio circuit, hifi radio (1 of 2) -> CD AF-
Wiring diagram cd af- (3 of 3)
ANTENNA
ANTENNA DIVERSITY (LEFT SIDE OF REAR COMPT)
AV SOCKET AV SOCKET NAVI +
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
CD AF+ L CD AF+ R
CD AF-
CD CHANGER
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (LEFT FRONT LUGGAGE COMPT)
FM AMPLIFIER
FM ANTENNA
FUSE
GROUND ANTENNA LIGHT TERM 30 TERM R
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN, ACC OR START
K-BUS MUTE
LEFT TV ANTENNA
NAVIGATION SYSTEM (REAR CENTER CONSOLE)
NCA WIRE
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
R - L -
RADIO
RADIO NAVI AV SOCKET SH NAVI -
RED/BLU WIRE
RED/YEL WIRE
RIGHT TV ANTENNA
TELEPHONE TRANSCEIVER
VIDEO MODULE (REAR CENTER OF REAR COMPT)
VIO/WHT WIRE
VOICE CONTROL SYSTEM
W/ ANTENNA DIVERSITY
W/ VIDEO MODULE
W/O ANTENNA DIVERSITY
W/O VIDEO MODULE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Premium radio circuit, top hifi radio (1 of 2) -> CD AF-
