Exterior lamps circuit for BMW Z4 E85/E86 (2002-2005)

BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM FUSE GRN/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM INTERIOR LIGHTS SYSTEM HOT AT ALL TIMES HOT IN ACC RUN AND START HOT IN RUN AND START LEFT FRONT TURN SIGNAL REPEATER LEFT HEAD- LIGHT LIGHT SWITCH CLUSTER LIGHT SWITCH CONTROLS LT BRK LGHT SIG TERM 30 LT LO BEAM SIG RT HI BEAM SIG POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED/GRN WIRE RED/VIO WIRE RIGHT FRONT TURN SIGNAL REPEATER RIGHT HEAD- LIGHT TURN SIGNAL LAMP VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

AUXILIARY BRAKE LIGHT BACK-UP LAMPS CIRCUIT BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH (NEAR STEERING COLUMN) BRN WIRE BRN/BLK WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DIRECTION INDICATOR/ HIGH-BEAM SWITCH GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HAZARD WARNING/ CENTRAL LOCKING SWITCH INSTRUMENT CLUSTER CONTROL MODULE LEFT LICENSE PLATE LIGHT LEFT REAR SIDE MARKER LIGHT LEFT TAILLIGHT RIGHT TAILLIGHT RIGHT LICENSE PLATE LIGHT RIGHT REAR SIDE MARKER LIGHT VIO/YEL WIRE WHT WIRE WHT/RED/YEL WIRE YEL/RED WIRE
