BMW Z4 E85/E86 (2002-2005) passenger's passenger's height backrest adjustment adjustment motor motor Wiring diagram
This page shows the only wiring diagram for the component.passenger's passenger's height backrest adjustment adjustment motor motor, which is found in the car BMW Z4 E85/E86 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's passenger's height backrest adjustment adjustment motor motor (1 of 1)
ANGLE
BACK
BACKREST
BLK WIRE
BLU WIRE
BRN WIRE
FRONT
FRONT DN UP
FUSE
FWD/BWD
GRN WIRE
GRY WIRE
HEIGHT
HOT AT ALL TIMES
NCA WIRE
PASSENGER'S FORWARD/ BACKWARD ADJUSTMENT MOTOR
PASSENGER'S PASSENGER'S HEIGHT BACKREST ADJUSTMENT ADJUSTMENT MOTOR MOTOR
PASSENGER'S SEAT ADJUSTMENT SWITCH
PASSENGER'S SEAT ANGLE ADJUSTMENT MOTOR
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RED WIRE
VIO WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> PASSENGER'S PASSENGER'S HEIGHT BACKREST ADJUSTMENT ADJUSTMENT MOTOR MOTOR
