BMW Z4 E85/E86 (2002-2005) mix air temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.mix air temperature sensor, which is found in the car BMW Z4 E85/E86 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mix air temperature sensor (1 of 1)
28 35 COOL TEMP SIG COOL TEMP
29 4 38 39 A/C COMP FAN COOL OUT TEMP COOL OUT TEMP
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLOWER OUTPUT STAGE (RIGHT SIDE OF DASH)
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLK WIRE
DEFROSTER FLAP MOTOR (RIGHT SIDE OF DASH)
DIGITAL MOTOR ELECTRONICS (DME) CONTROL UNIT (LEFT REAR OF ENGINE COMPT)
ELECTRIC FAN
ENGINE COOLANT TEMPERATURE SENSOR
EVAPORATIVE TEMPERATURE SENSOR (LEFT SIDE OF DASH)
FOOTWELL FLAP MOTOR (RIGHT SIDE OF DASH)
FUSE
GRN WIRE
HOT AT ALL TIMES
MIX AIR TEMPERATURE SENSOR
MIXER FLAP MOTOR (RIGHT SIDE OF DASH)
NCA WIRE
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
REMOTE TEMPERATURE SENSOR
VENTILATION FLAP MOTOR (RIGHT SIDE OF DASH)
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> MIX AIR TEMPERATURE SENSOR
