BMW Z4 E85/E86 (2002-2005) brn Wiring diagrams

This page contains all the electrical diagrams for the component. brn, in which he is found in the car BMW Z4 E85/E86 (2002-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram brn (41 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (41 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE DRIVER'S DOOR MODULE DRIVER'S SIDE OUTSIDE MIRROR ELECTRO- CHROMIC ACTIVATION ELECTROCHROMIC INTERIOR REAR VIEW MIRROR EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS) FUSE GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH) GRN WIRE GRN/WHT WIRE GRY/BLK/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START NCA WIRE PASSENGER'S SIDE OUTSIDE MIRROR POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE RED/GRN WIRE SECURITY WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component -> Electrochromic mirror circuit -> BRN WIRE

Wiring diagram brn (42 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (42 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

1 2 3 4 5 6 7 8 9 10 11 12 D MOTOR D MOTOR TERM 30 ANTI-LOCK BRAKES SYSTEM BLU WIRE BRN WIRE DRIVER'S DOOR MODULE DRIVER'S SIDE OUTSIDE MIRROR FOLD-IN MOTOR FUSE GRN WIRE HOT AT ALL TIMES MIRROR FOLD-IN SWITCH NCA WIRE OUTSIDE MIRROR FOLD-IN P MOTOR P MOTOR PASSENGER'S SIDE OUTSIDE MIRROR POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRN/YEL WIRE RED/WHT WIRE SPEED SIG SWITCH TERM 31 VIO WIRE WHT WIRE WHT/GRN WIRE

Go to component -> Fold-back mirrors circuit -> BRN WIRE

Wiring diagram brn (43 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (43 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

BRN WIRE CENTER CONSOLE SWITCH CENTER COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST HEATER DRIVER'S SEAT HEATER FUSE GRN/VIO WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN START, RUN OR ACC PASSENGER'S BACKREST HEATER PASSENGER'S SEAT HEATER POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED/YEL WIRE

Go to component -> Heated seats circuit -> BRN WIRE

Wiring diagram brn (44 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (44 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

BLK WIRE BLU WIRE BRN WIRE DRIVER'S LUMBAR SUPPORT SWITCH DRIVER'S LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT LUMBAR SUPPORT MOTOR FUSE GRY WIRE HOT AT ALL TIMES LUMBAR SUPPORT VALVE BLOCK NCA WIRE PASSENGER'S LUMBAR SUPPORT SWITCH PASSENGER'S SEAT LUMBAR SUPPORT MOTOR POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE VIO WIRE WHT WIRE

Go to component -> Lumbar circuit -> BRN WIRE

Wiring diagram brn (45 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (45 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

ANGLE BACK BACKREST BLK WIRE BLU WIRE BRN WIRE FRONT FRONT DN UP FUSE FWD/BWD GRN WIRE GRY WIRE HEIGHT HOT AT ALL TIMES NCA WIRE PASSENGER'S FORWARD/ BACKWARD ADJUSTMENT MOTOR PASSENGER'S PASSENGER'S HEIGHT BACKREST ADJUSTMENT ADJUSTMENT MOTOR MOTOR PASSENGER'S SEAT ADJUSTMENT SWITCH PASSENGER'S SEAT ANGLE ADJUSTMENT MOTOR POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE VIO WIRE YEL WIRE

Go to component -> Passenger power seat circuit -> BRN WIRE

Wiring diagram brn (46 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (46 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

BLU WIRE BRAKE LIGHT SWITCH BRN WIRE CENTER CONSOLE SWITCH CENTER CLUTCH SWITCH CRUISE CONTROL STEERING COLUMN SWITCH EJECT BOX ELECTRONIC VEHICLE IMMOBLIZER FROM FROM IGNITION SWITCH (DIAGRAM 5 OF 6) FUSE GENERAL MODULE CONTROL UNIT HORN RELAY INSTRUMENT CLUSTER CONTROL MODULE LIGHT SWITCH CLUSTER NAVIGATION SYSTEM NCA WIRE POWER DISTRIBUTION (RIGHT SIDE OF DASH) RADIO RAIN/ HEADLIGHT SENSOR SAFETY INFORMATION MODULE SEAT OCCUPANCY RECOGNITION TELEPHONE TRANSCEIVER TO FUSE VIO WIRE VOICE CONTROL SYSTEM VOLUTE SPRING WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (6 of 6) -> BRN WIRE

Wiring diagram brn (47 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (47 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRY/YEL WIRE DRIVER'S DOOR SYSTEM LOCK ELECTRONIC INTERIOR REAR-VIEW MIRROR FUSE GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH) GRN WIRE GRN/BRN WIRE GRY WIRE GRY/BLK/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE HAZARD WARNING/ CENTRAL LOCKING SWITCH HOT AT ALL TIMES HOT AT ALL TIMES FUSE NCA WIRE ODDMENTS COMPARTMENT CENTRAL LOCKING DRIVE PASSENGER'S DOOR SYSTEM LOCK POWER DISTRIBUTION (RIGHT SIDE OF DASH) REAR LID RELEASE SWITCH (INTERIOR) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE TRUNK LID/ TAILGATE LOCK SWITCH TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE WHT/BLK WIRE YEL/RED WIRE

Go to component -> Power door locks circuit -> BRN WIRE

Wiring diagram brn (48 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (48 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR MODULE DRIVER'S SIDE OUTSIDE MIRROR FUSE GRN WIRE GRY WIRE HEATING HOT IN RUN OR START NCA WIRE PASSENGER'S SIDE OUTSIDE MIRROR POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE VERT HORIZ WHT WIRE

Go to component -> Power mirrors circuit -> BRN WIRE

Wiring diagram brn (49 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (49 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

1 2 3 4 5 6 VOLTAGE SUPPLY SENSOR SIG SENSOR SIG SENSOR SIG SENSOR SIG BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE CENTER CONSOLE SWITCH CENTER COMPUTER DATA LINES SYSTEM CONVERTIBLE SOFT TOP SWITCH CLOSED CONVERTIBLE TOP COMPARTMENT FLOOR SWITCH CONVERTIBLE TOP DRIVE CONVERTIBLE TOP LOWERED SWITCH CONVERTIBLE TOP MODULE (LEFT REAR PASSENGER COMPT) CONVERTIBLE TOP RELAY 1 (RIGHT SIDE OF DASH) CONVERTIBLE TOP RELAY 2 (RIGHT SIDE OF DASH) FUSE GRY WIRE HARDTOP LOCATING POINT 1 HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE K- BUS LOCKING COWL PANEL DRIVE NCA WIRE POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE SCUTTLE LOCKED SWITCH SCUTTLE RELEASED SWITCH WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED/YEL WIRE YEL WIRE

Go to component -> Power top/sunroof circuit -> BRN WIRE

Wiring diagram brn (50 of 66)

Wiring diagram brn for BMW Z4 E85/E86 (2002-2005) (50 of 66)
Get lifetime access to BMW Z4 E85/E86 (2002-2005)

15 8 GND PWR FRONT WINDOW REG DRVR PWR WNDW MTR 40 4 41 5 PASS WNDW REG CLOSED FRNT PASS PWR WNDW SW BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BLU/VIO WIRE BRN WIRE DRIVER'S DOOR MODULE DRIVER'S WINDOW MOTOR DRVR PWR WNDW MTR DRVR PWR WNDW SW CLOSED DRIVER PWR WNDW SW FR PASS PWR WND MTR FR PASS PWR WNDW MTR GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH) GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES FUSE NCA WIRE PASSENGER'S DOOR POWER WINDOW SWITCH PASSENGER'S WINDOW MOTOR POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE RED/GRN WIRE YEL WIRE

Go to component -> Power windows circuit -> BRN WIRE
