BMW Z4 E85/E86 (2002-2005) 2005 only wiring diagram
This page shows the only wiring diagram for the component.2005 only, which is found in the car BMW Z4 E85/E86 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
2005 only wiring diagram (1 of 1)
2005 ONLY
2006 ONLY
BRAKES SOLENOID VALVE
BRN WIRE
CLUTCH SOLENOID VALVE
CONVERTIBLE TOP RELAY 1
CONVERTIBLE TOP RELAY 2
DME CONTROL MODULE
DME CONTROL MODULE OIL LEVEL SENSOR
FOLD-IN OUTSIDE MIRROR
FRONT INTERIOR/ READING LAMP
FUEL INJECTORS RELAY
GEAR SHIFT LEVER LIGHTING
GEAR SOLENOID VALVE 1
GEAR SOLENOID VALVE 2
HEATING/ AIR CONDITIONING SYSTEM BLOWER OUTPUT STAGE
HYDRAULIC PUMP RELAY
IGNITION COIL (CYL 2) IGNITION COIL (CYL 1)
IGNITION COIL (CYL 4) IGNITION COIL (CYL 3)
IGNITION COIL (CYL 5)
IGNITION COIL (CYL 6)
NCA WIRE
OIL LEVEL SENSOR
PASSENGER'S DOOR HANDLE LIGHTING
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S DOOR SYSTEM LOCK
PASSENGER'S SEAT ADJUSTMENT SWITCH GENERAL MODULE CONTROL MODULE
PASSENGER'S SEAT BACKREST HEATING
PASSENGER'S SEAT CUSHION HEATING
PASSENGER'S SIDE FOOTWELL LIGHT
PASSENGER'S SIDE OUTSIDE MIRROR
PASSENGER'S WINDOW MOTOR
POWER DISTRIBUTION
SEQUENTIAL MANUAL TRANSMISSION RPM SENSOR SHIELD
TOP OF ENGINE)
TRANSMISSION CONTROL
Go to component -> Ground distribution circuit (3 of 3) -> 2005 ONLY
