Convertible top circuit for BMW Z3 E36 facelift (2000-2002)
Convertible top circuit
1) TOP TENSION RELIEVED 2) TOP FULLY EXTENDED
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
BRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
CLOSE OPEN
CONVERTIBLE TOP ACTUATING SWITCH
CONVERTIBLE TOP END-POSITION MICROSWITCH
CONVERTIBLE TOP MOTOR (LEFT SIDE OF LUGGAGE COMPT)
CONVERTIBLE TOP RELAY 1 (CLOSE) (LEFT SIDE OF LUGGAGE COMPT)
CONVERTIBLE TOP RELAY 2 (OPEN) (LEFT SIDE OF LUGGAGE COMPT)
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPT)
FUSE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN, START FUSE
NCA WIRE
RED WIRE
YEL WIRE
