On-board computer circuit for BMW Z3 E36 facelift (2000-2002)
On-board computer circuit
BLK/WHT WIRE
BRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/YEL WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM INSTRUMENT CLUSTER CIRCUIT
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPARTMENT)
FUSE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN, START
INSTRUMENT CLUSTER CIRCUIT
ON-BOARD COMPUTER
ON-BOARD COMPUTER TEMPERATURE SENSOR (IN RIGHT FRONT BUMPER)
RED WIRE
RED/YEL WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/VIO WIRE
WHT/YEL WIRE
