Park, stop, tail & license plate lamps circuit, usa for BMW Z3 E36 facelift (2000-2002)
Park, stop, tail & license plate lamps circuit, usa
BLU/RED WIRE
BODY ELECTRONIC CONTROL MODULE (BEHIND GLOVE BOX)
BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
BRN WIRE
COUPE ROADSTER COUPE ROADSTER LEFT TAIL- LIGHT LEFT TAIL- LIGHT
DYNAMIC STABILITY CONTROL UNIT (LEFT SIDE OF ENGINE COMPARTMENT
ENGINE CONTROL MODULE (RIGHT REAR SIDE OF ENGINE COMPARTMENT)
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPARTMENT)
FUSE
GRY/BLK WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEAD OFF PARK
HIGH LEVEL STOP LIGHT
HOT AT ALL TIMES
HOT IN ACCY, RUN, START
HOT IN RUN, START
LEFT BRAKE LIGHT
LEFT HEAD- LIGHT LEFT FRONT MARKER LIGHT LEFT PARK LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR LIGHT ASSEMBLY
LIGHT SWITCH
POWER TOPS SYSTEM
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT BRAKE LIGHT
RIGHT FRONT MARKER LIGHT
RIGHT HEAD- LIGHT RIGHT PARK LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR LIGHT ASSEMBLY
ROADSTER COUPE COUPE ROADSTER RIGHT TAIL- LIGHT RIGHT TAIL- LIGHT
SLIP CONTROL MODULE (LEFT FRONT SIDE OF ENGINE COMPARTMENT)
TRANSMISSION CONTROL MODULE (RIGHT REAR SIDE OF ENGINE COMPARTMENT)
VIO/YEL WIRE
W/ ASC
W/ DSC
WIPER/ WASHER MODULE (BEHIND GLOVE BOX)
