BMW Z3 E36 facelift (2000-2002) supplemental restraint control module wiring diagram
This page shows the only wiring diagram for the component.supplemental restraint control module, which is found in the car BMW Z3 E36 facelift (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
supplemental restraint control module wiring diagram (1 of 1)
AUXILIARY FUSE BOX (UNDER LEFT SIDE OF DASH) FUSE FUSE FUSE
B+ JUMP
B+ JUNCTION POINT (UNDER LEFT SIDE OF DASH)
B+ JUNCTION POINT E-BOX (RIGHT REAR OF ENGINE COMPARTMENT)
BATTERY
BATTERY SAFETY TERMINAL (RIGHT SIDE OF LUGGAGE COMPARTMENT)
BLU WIRE
BODY
BRN WIRE
CAMSHAFT POSITION SENSOR 1
CAMSHAFT POSITION SENSOR 2
CRANKSHAFT POSITION/ RPM SENSOR
CYLINDER CYLINDER CYLINDER IGNITION IGNITION IGNITION COIL 1 COIL 2 COIL 3
DYNAMIC STABILITY CONTROL (DSC) UNIT
EARLY PRODUCTION (W/ DSC)
ENGINE CONTROL MODULE RELAY
FRONT POWER DISTRIBUTION BOX (LEFT REAR OF ENGINE COMPT)
FRONT POWER DISTRIBUTION BOX (LEFT REAR OF ENGINE COMPT) FUSE
FUSE
FUSE FUSE
FUSE FUSE FUSE
FUSE HOLDER (RIGHT SIDE OF LUGGAGE COMPARTMENT) FUSE
FUSE HOLDER IN E-BOX (RIGHT REAR OF ENGINE COMPARTMENT)
GENERATOR STARTER
INJECTION VALVES RELAY
JUNCTION POINT (RIGHT REAR OF ENGINE COMPARTMENT)
LATE PRODUCTION W/ DSC
NCA WIRE
RED WIRE
RED/BLK/WHT WIRE
RED/BLU WIRE
RED/BLU/YEL WIRE
RED/GRN WIRE
RED/GRN/YEL WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
SECONDARY AIR PUMP RELAY
SECONDARY TRANSMISSION AIR PUMP CONTROL RELAY MODULE (EGS)
SUPPLEMENTAL RESTRAINT CONTROL MODULE
THERMOSTAT HOT FILM MASS AIR CHARAC- TERISTIC METER MAP COOLING
TO FUSE
TO IGNITION SWITCH (DIAGRAM 3 OF 4)
TRANS ENGINE CONTROL CONTROL MODULE MODULE (EGS)
WIPER/ WASHER MODULE
Go to component -> Power distribution circuit (1 of 4) -> SUPPLEMENTAL RESTRAINT CONTROL MODULE
