BMW Z3 E36 facelift (2000-2002) seat mat wiring diagram
This page shows the only wiring diagram for the component.seat mat, which is found in the car BMW Z3 E36 facelift (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
seat mat wiring diagram (1 of 1)
AIR BAG
BATTERY SAFETY TERMINAL (NEAR BATTERY)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/VIO/YEL WIRE
BLU/WHT/YEL WIRE
BODY ELECTRONICS CONTROL MODULE (BEHIND GLOVE BOX)
BPT+ BPT-
BRN WIRE
BRN/BLK WIRE
BRN/GRN/WHT WIRE
BRN/ORG WIRE
BRN/VIO WIRE
CONTACT RING
DATA LINK CONNECTOR (DLC) (PARTIAL) (ON LEFT REAR SIDE OF ENGINE COMPARTMENT)
DRIVER'S AIR BAG GAS GENERATOR
DRIVER'S SEAT BELT SWITCH (IN DRIVER'S FRONT SEAT BELT BUCKLE)
DRIVER'S SIDE IMPACT SENSOR (UNDER LEFT FRONT SEAT)
DRIVER'S SIDE PYROTECHNICAL BELT TENSIONER (IN LEFT FRONT SEAT BELT BUCKLE)
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPARTMENT)
FUSE 27
FUSE 41
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
HOT IN ACCY, RUN, START
HOT IN RUN, START
INSTRUMENT CLUSTER
LEFT SIDE AIR BAG GAS GENERATOR
NCA WIRE
ORG/ WIRE
PASSENGER SIDE IMPACT SENSOR (UNDER RIGHT FRONT SEAT)
PASSENGER'S AIR BAG GAS GENERATOR
PASSENGER'S SEAT BELT SWITCH (IN PASSENGER'S FRONT SEAT BELT BUCKLE)
PASSENGER'S SIDE PRYOTECHNICAL BELT TENSIONER (IN RIGHT FRONT SEAT BELT BUCKLE)
RED WIRE
RIGHT SIDE AIR BAG GAS GENERATOR
SBE
SEAT BELT WARNING LAMP
SEAT MAT
SEAT OCCUPANCY DETECTOR (UNDER RIGHT FRONT SEAT)
SOLID STATE
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL MODULE (BELOW CENTER CONSOLE)
VIO WIRE
VIO/BLU WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit -> SEAT MAT
