BMW Z3 E36 facelift (2000-2002) pressure transmitter Wiring diagrams
This page contains all the electrical diagrams for the component. pressure transmitter, in which he is found in the car BMW Z3 E36 facelift (2000-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pressure transmitter (1 of 2)
ABS IND.
AUXILIARY FUSE BOX (UNDER LEFT SIDE OF DASH)
BLK/GRN WIRE
BLK/RED/WHT WIRE
BLK/RED/YEL WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN/YEL WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT/YEL WIRE
BRAKE FLUID IND
BRAKE FLUID LEVEL SWITCH (LEFT REAR SIDE OF ENGINE COMPT)
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK/WHT WIRE
BRN/BLK/YEL WIRE
BRN/RED WIRE
BRN/VIO WIRE
DATA LINK CONNECTOR (REAR ENGINE COMPT)
DSC SWITCH
DYNAMIC STABILITY CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FRONT POWER DISTRIBUTION BOX (ON LEFT REAR CORNER OF ENG COMPT)
FUSE
GRN WIRE
GRN/BLK/YEL WIRE
GRN/BLU WIRE
GRN/BLU/YEL WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN, START
HOT IN RUN AND START
INSTRUMENT CLUSTER
LEFT FRONT ABS SPEED SENSOR
LEFT REAR ABS SPEED SENSOR
NCA WIRE
PARKING BRAKE SWITCH
PRECHARGE PUMP (LEFT REAR SIDE OF ENGINE COMPT)
PRESSURE SENSOR (LEFT REAR SIDE OF ENGINE COMPT)
PRESSURE TRANSMITTER
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL BLK/ WIRE
RED/YEL WIRE
RIGHT FRONT ABS SPEED SENSOR
RIGHT REAR ABS SPEED SENSOR
RPM RATE SENSOR (UNDER DRIVER'S SEAT)
STEERING ANGLE SENSOR (ON STEERING COLUMN)
TRANSVERSE ACCELERATION SENSOR (UNDER DRIVERS'S SEAT)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Anti-lock brakes circuit, with dsc early production -> PRESSURE TRANSMITTER
Wiring diagram pressure transmitter (2 of 2)
ABS IND.
AUXILIARY FUSE BOX (UNDER LEFT SIDE OF DASH)
BLK/RED/YEL WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN/YEL WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRAKE FLUID IND
BRAKE FLUID LEVEL SWITCH (LEFT REAR SIDE OF ENGINE COMPT)
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK/WHT WIRE
BRN/BLK/YEL WIRE
BRN/RED WIRE
BRN/VIO WIRE
DATA LINK CONNECTOR (REAR ENGINE COMPT)
DSC SWITCH
DYNAMIC STABILITY CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
FRONT POWER DISTRIBUTION BOX (ON LEFT REAR CORNER OF ENG COMPT)
FUSE
GRN WIRE
GRN/BLK/YEL WIRE
GRN/BLU WIRE
GRN/BLU/YEL WIRE
GRN/VIO WIRE
GRY/BLK/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN, START
HOT IN RUN AND START
INSTRUMENT CLUSTER
LEFT FRONT ABS SPEED SENSOR
LEFT REAR ABS SPEED SENSOR
NCA WIRE
PARKING BRAKE SWITCH
PRESSURE SENSOR (LEFT REAR SIDE OF ENGINE COMPT)
PRESSURE TRANSMITTER
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT ABS SPEED SENSOR
RIGHT REAR ABS SPEED SENSOR
RPM RATE SENSOR (UNDER DRIVER'S SEAT)
STEERING ANGLE SENSOR (ON STEERING COLUMN)
TRANSVERSE ACCELERATION SENSOR (UNDER DRIVERS'S SEAT)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Anti-lock brakes circuit, with dsc late production -> PRESSURE TRANSMITTER
