BMW Z3 E36 facelift (2000-2002) convertible top end-position microswitch Wiring diagram
This page shows the only wiring diagram for the component.convertible top end-position microswitch, which is found in the car BMW Z3 E36 facelift (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top end-position microswitch (1 of 1)
1) TOP TENSION RELIEVED 2) TOP FULLY EXTENDED
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
BRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
CLOSE OPEN
CONVERTIBLE TOP ACTUATING SWITCH
CONVERTIBLE TOP END-POSITION MICROSWITCH
CONVERTIBLE TOP MOTOR (LEFT SIDE OF LUGGAGE COMPT)
CONVERTIBLE TOP RELAY 1 (CLOSE) (LEFT SIDE OF LUGGAGE COMPT)
CONVERTIBLE TOP RELAY 2 (OPEN) (LEFT SIDE OF LUGGAGE COMPT)
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPT)
FUSE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN, START FUSE
NCA WIRE
RED WIRE
YEL WIRE
Go to component -> Convertible top circuit -> CONVERTIBLE TOP END-POSITION MICROSWITCH
