BMW Z3 E36 facelift (2000-2002) below 21 bar Wiring diagram
This page shows the only wiring diagram for the component.below 21 bar, which is found in the car BMW Z3 E36 facelift (2000-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram below 21 bar (1 of 1)
ABOVE 2.6 BAR
ABOVE 30 BAR
AUXILIARY FAN MOTOR
BELOW 1.5 BAR
BELOW 15 BAR ABOVE 18 BAR
BELOW 21 BAR
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
EVAPORATOR CONTROLLER (ON RIGHT SIDE OF LEFT FOOTWELL)
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPT)
FUSE 16 FUSE 40
GRN/BLU WIRE
GRN/RED WIRE
HIGH SPEED RELAY (IN FRONT POWER DISTRIBUTION BOX)
HOT IN RUN, START HOT AT ALL TIMES
INSTRUMENT CLUSTER
NCA WIRE
NORMAL SPEED RELAY (IN FRONT POWER DISTRIBUTION BOX)
PRESSURE SWITCH (NEAR RIGHT HEADLIGHT)
RED/GRN WIRE
TEMPERATURE SWITCH (RIGHT FRONT OF ENGINE COMPT)
VIO WIRE
Go to component -> Cooling fan circuit -> BELOW 21 BAR
