Shift interlock circuit for BMW Z3 E36 (1995-2000)
Shift interlock circuit
AUTOMATIC TRANSMISSION RANGE SWITCH (IN CENTER CONSOLE, AT SHIFTER)
B+ JUNCTION POINT
BATTERY VOLTAGE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
BRAKE PEDAL POSITION
BRN WIRE
BRN/BLK WIRE
BRN/ORG (OR BRN) WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/WHT WIRE
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPT)
FUSE
GEAR RANGE
GRN/GRY WIRE
GROUND
HOT AT ALL TIMES
HOT IN RUN AND START
HOT IN RUN, ACC AND START
NCA WIRE
RED WIRE
SHIFT LOCK SOLENOID CONTROL
SHIFT LOCK SOLENOID GROUND GEAR RANGE
SHIFT-LOCK (UNDER CENTER CONSOLE, AT SHIFTER)
TRANSMISSION CONTROL MODULE (RIGHT REAR CORNER OF ENGINE COMPT)
TRANSMISSION SYSTEM (1.9L ONLY)
VIO WIRE
VIO/YEL WIRE
