Back-up lamps circuit for BMW Z3 E36 (1995-2000)
Back-up lamps circuit
A/T RANGE SWITCH (CENTER CONSOLE)
BLU WIRE
BLU/YEL WIRE
BRN WIRE
FRONT POWER DISTRIBUTION BOX (LEFT REAR CORNER OF ENGINE COMPARTMENT)
FUSE 26
GRN WIRE
HOT IN RUN AND START
LEFT BACK-UP LIGHT
LEFT REAR LIGHT ASSEMBLY
REVERSING LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
RIGHT BACK-UP LIGHT
RIGHT REAR LIGHT ASSEMBLY
W/ EGS
W/O EGS
WHT WIRE
YEL WIRE
