BMW Z3 E36 (1995-2000) single off inter Wiring diagram
This page shows the only wiring diagram for the component.single off inter, which is found in the car BMW Z3 E36 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram single off inter (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/RED/YEL WIRE
BLK/WHT WIRE
BLK/WHT/YEL WIRE
BRN WIRE
BRN/GRN/YEL WIRE
BRN/VIO WIRE
EXTERIOR LIGHTS (MAIN LIGHT SWITCH)
FAST
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN AND START
INSTRUMENT CLUSTER
NCA WIRE
NORML
PARK
RED/BLU/YEL WIRE
RED/BRN/YEL WIRE
RUN WIRE
SINGLE OFF INTER
VEHICLE SPEED SIGNAL
VIO/BLK WIRE
W/ HEADLIGHT WASHER
W/O HEAD- LIGHT WASHER
WASH
WASHER PUMP (FRONT RIGHT SIDE OF ENGINE COMPT, ON WASHER FLUID RESERVOIR)
WIPER MOTOR (REAR OF ENGINE COMPARTMENT)
WIPER/WASHER MODULE (BEHIND GLOVE BOX)
WIPER/WASHER SWITCH
Go to component -> Wiper/washer circuit -> SINGLE OFF INTER
