BMW Z3 E36 (1995-2000) set decelerate/ Wiring diagram
This page shows the only wiring diagram for the component.set decelerate/, which is found in the car BMW Z3 E36 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram set decelerate/ (1 of 1)
1996 1997-98
AUTOMATIC TRANSMISSION RANGE SWITCH (CENTER CONSOLE)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE LIGHT SWITCH (TOP OF BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CLUTCH SWITCH (TOP OF CLUTCH PEDAL SUPPORT)
CRUISE CONTROL ACTUATOR (LEFT FRONT SIDE OF ENGINE COMPARTMENT)
CRUISE CONTROL MODULE (UNDER RIGHT SIDE OF DASH, BEHIND GLOVE BOX)
CRUISE CONTROL SWITCH
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GRN WIRE
GRY WIRE
HOT IN ACCY, RUN AND START
HOT IN RUN AND START
INSTRUMENT CLUSTER
JUMPER PLUG (LEFT KICK PANEL)
NCA WIRE
NORMAL
OFF
ORG/ WIRE
RED WIRE
RESUME
SET ACCCELERATE/
SET DECELERATE/
TRANSMISSION SYSTEM
VEHICLE SPEED SENSOR
VIO WIRE
VIO/YEL WIRE
W/ EGS
W/O EGS
WHT WIRE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit -> SET DECELERATE/
