BMW Z3 E36 (1995-2000) left door jamb switch Wiring diagram
This page shows the only wiring diagram for the component.left door jamb switch, which is found in the car BMW Z3 E36 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left door jamb switch (1 of 1)
ASC SWITCH
BODY ELECTRONICS CONTROL MODULE
BRAKE LIGHT SWITCH
BRN WIRE
CD CHANGER
CHIME MODULE
COMBINATION SWITCH (HORN SWITCH)
CONVERTIBLE TOP ACTUATING SWITCH
CONVERTIBLE TOP RELAY I (CLOSE)
CONVERTIBLE TOP RELAY LL (OPEN)
CONVERTIBLE TOP-END POSITION MICRO- SWITCH
ELECTRONIC IMMOBILIZER CONTROL MODULE
FRONT ASHTRAY LIGHT
FUEL PUMP
HARD TOP CONN- ECTOR 1
HAZARD SWITCH
HIFI AMPLIFIER
HIGH LEVEL STOP LIGHT
LEFT BRAKE LIGHT LEFT BACK-UP LIGHT
LEFT DOOR JAMB SWITCH
LEFT LICENSE PLATE LIGHT
LEFT REAR LIGHT ASSEMBLY
LEFT REAR TURN LIGHT
LEFT SEAT CONTROL SWITCH
LEFT SEAT HEATER
LEFT SEAT HEATER SWITCH
LEFT SEAT LENGTH ADJUST CUT-OFF RELAY
LEFT SEAT LIMIT SWITCH
LEFT SEAT TILT ADJUST CUT-OFF RELAY
LEFT SEATBACK HEATER
LEFT TAIL LIGHT LEFT TAIL LIGHT
LIGHT SWITCH
LUGGAGE COMPARTMENT LIGHT SWITCH
NCA WIRE
OBD II CONNECTOR DIGITAL CLOCK
PROGRAM SWITCH
RADIO
RADIO ANTI- THEFT SWITCH
REAR DEFOGGER 1
REAR WINDOW DEFOGGER SWITCH
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT
RIGHT FRONT AUXILIARY TURN LIGHT
RIGHT FRONT SPEED SENSOR FRONT CIGAR LIGHTER LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR BRAKE PAD SENSOR
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR TURN LIGHT
RIGHT SEAT CONTROL SWITCH
RIGHT SEAT HEATER
RIGHT SEAT HEATER SWITCH RIGHT AIR BAG CUT-OFF SWITCH
RIGHT SEATBACK HEATER
RIGHT TAIL LIGHT
TELEPHONE CONNECTOR
TRANSMISSION POSITION INDICATOR LIGHT
W/ SPORT SEAT PACKAGE
W/O HARD TOP PRO- VISION W/ HARD TOP PRO- VISION
W/O SPORT SEAT PACKAGE
Go to component -> Ground distribution circuit (3 of 3) -> LEFT DOOR JAMB SWITCH
