BMW Z3 E36 (1995-2000) computer data lines system computer data lines system engine controls system Wiring diagram
This page shows the only wiring diagram for the component.computer data lines system computer data lines system engine controls system, which is found in the car BMW Z3 E36 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines system computer data lines system engine controls system (1 of 1)
BLK/WHT WIRE
BRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/RED WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN ACCY, RUN AND START
INSTRUMENT CLUSTER SYSTEM
NCA WIRE
OF ENGINE COMPT)
ON-BOARD COMPUTER
ON-BOARD COMPUTER TEMPERATURE SENSOR
RED/YEL WIRE
VIO/YEL WIRE
WHEELWELL)
WHT/BLK WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> On-board computer circuit -> COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM
