BMW Z3 E36 (1995-2000) combination switch high beam switch normal Wiring diagram
This page shows the only wiring diagram for the component.combination switch high beam switch normal, which is found in the car BMW Z3 E36 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch high beam switch normal (1 of 1)
BRN WIRE
COMBINATION SWITCH HIGH BEAM SWITCH NORMAL
CRASH CONTROL MODULE (LEFT SIDE OF DASH)
EXTERIOR LIGHTS
FLASH HIGH
FOG LIGHT SWITCH
FOG LIGHTS INDICATOR
FRONT FOG LIGHT RELAY (POWER DISTRIBUTION BOX)
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPT.)
FUSE
GRN RED/ WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HIGH BEAM LIGHT RELAY (ON RELAY PANEL, UNDER LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN RUN AND START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER HIGH BEAM INDICATOR
LEFT FOG LIGHT RIGHT FOG LIGHT
LEFT HIGH BEAM LIGHT RIGHT HIGH BEAM LIGHT
LEFT LOW BEAM LIGHT
LIGHT SWITCH
LOW BEAM LIGHT RELAY (POWER DISTRIBUTION BOX)
NOT USED NOT USED
OFF HEAD PARK
RED GRN/ WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT LOW BEAM LIGHT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL GRN/ WIRE
YEL GRY/ WIRE
YEL VIO/ WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> Headlight circuit -> COMBINATION SWITCH HIGH BEAM SWITCH NORMAL
