BMW Z3 E36 (1995-2000) close auto Wiring diagram
This page shows the only wiring diagram for the component.close auto, which is found in the car BMW Z3 E36 (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram close auto (1 of 1)
** (BEHIND GLOVE BOX) (RIGHT SIDE OF GLOVE BOX)
3 6 ** DRIVERS POWER WINDOW SWITCH
3 6 ** PASSENGERS POWER WINDOW SWITCH
4 5 **
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BODY ELECTRONICS CONTROL MODULE (ZKE IV) (BEHIND GLOVE BOX)
BRN WIRE
BRN/BLU/YEL WIRE
BRN/GRY/YEL WIRE
CLOSE AUTO
CLOSE WDO
DRIVER'S POWER WINDOW MOTOR
DRIVERS DOOR JAMB SWITCH
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GRY/RED WIRE
HOT AT ALL TIMES
OFF
OPEN AUTO
OPEN WDO
PASSENGER'S DOOR JAMB SWITCH
PASSENGER'S POWER WINDOW MOTOR
RED/BLU WIRE
STARTER
VIO/WHT WIRE
WHT/GRN WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Power window circuit -> CLOSE AUTO
