Exterior lamps circuit for BMW XM G09 (2022-2024)

AUXILIARY TURN SIGNAL LAMP BASIC CENTRAL PLATFORM (BCP) BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER VEHICLE EXTERIOR MIRROR DYNAMIC STABILITY CONTROL (DSC)/ VIRTUAL INTEGRATION PLATFORM (VIP) FRONT PASSENGER VEHICLE EXTERIOR MIRROR FUSE 1 FUSE 504 FUSE BOX GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED LEFT RADIATOR GRILLE LIGHTING LIGHT OPERATING SYSTEM RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT RADIATOR GRILLE LIGHTING STEERING COLUMN SWITCH CLUSTER VIO/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

AUXILIARY STOP LAMP BLK WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 213 FUSE 240 FUSE 267 FUSE 289 GRY/BRN WIRE HOT W/ INTERFERENCE SUPPRESSOR FILTER INTERFERENCE SUPPRESSOR FILTER 2 NUMBER PLATE W/ REAR LID BUTTON REAR FOG LIGHT CENTER REAR LIGHT REAR POWER DISTRIBUTION BOX RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RELAY ENERGIZED REVERSING LIGHT TRAILER BRAKE SYSTEM PLUG CONNECTION TRAILER SOCKET PREPARATION YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

BACKUP LAMP BRAKE LIGHT BRN WIRE COMPUTER DATA LINES SYSTEM LEFT INNER TAILLIGHT LEFT OUTER TAILLIGHT LEFT REAR INNER LIGHT MODULE (RLMIL) LEFT REAR OUTER LIGHT MODULE (RLMAR) NCA WIRE RIGHT INNER TAILLIGHT RIGHT OUTER TAILLIGHT RIGHT REAR OUTER LIGHT MODULE (RLMAR) RIGHT REAR INNER LIGHT MODULE (RLMIR) TAIL LAMP TURN INDICATOR YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE
