Exterior lamps circuit for BMW X7 G07 facelift (2022-2024)

AUXILIARY TURN SIGNAL LAMP BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRAKE LIGHT/ TURN SIGNAL BRN WIRE CENTER CONSOLE CONTROL COMPUTER DATA LINES SYSTEM DRIVER VEHICLE EXTERIOR MIRROR FUSE 1 FUSE 504 FUSE BOX GRN/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED LIGHT OPERATING UNIT NUMBER PLATE LIGHT W/ REAR LID BUTTON PARKING BRAKE BUTTON RED WIRE RED/YEL WIRE RIGHT INNER TAILLIGHT TAIL LAMP TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN SIGNAL/ DYNAMIC BRAKE LIGHT WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE

ACCENT LIGHT AIR CONDITIONING BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CORNERING LIGHT DRIVER ASSISTANCE SYSTEM OPERATING FACILITY, HAZARD WARNING SWITCH GRN/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE INNER PARKING LIGHTS/DAYTIME RUNNING LIGHTS LEFT FRONTAL LIGHT ELECTRONICS LEFT HEADLIGHT OUTER PARKING LIGHTS/DAYTIME RUNNING LIGHTS PARKING LIGHTS/ DAYTIME RUNNING LIGHTS 2 LED MODULE PARKING LIGHTS/ DAYTIME RUNNING LIGHTS LED MODULE RED/YEL WIRE SIDE MARKER LIGHT TURN INDICATOR WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

ACCENT LIGHT AUXILIARY STOP LAMP AUXILIARY TURN SIGNAL LAMP BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CORNERING LIGHT FRONT PASSENGER VEHICLE EXTERIOR MIRROR GRN/BLU WIRE GRY/VIO WIRE INNER PARKING LIGHTS/DAYTIME RUNNING LIGHTS INTERFERENCE SUPPRESSION FILTER NCA WIRE OUTER SIDE LIGHTS/DAYTIME RUNNING LIGHTS PARKING LIGHTS/ DAYTIME RUNNING LIGHTS 2 LED MODULE PARKING LIGHTS/ DAYTIME RUNNING LIGHTS LED MODULE RED/YEL WIRE RIGHT FRONTAL LIGHT ELECTRONICS RIGHT HEADLIGHT SIDE MARKER LIGHT TRAILER BRAKE SYSTEM PLUG CONNECTION TURN INDICATOR WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

BACKUP LAMPS CIRCUIT BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHT/ TURN SIGNAL BRN WIRE COMPUTER DATA LINES SYSTEM GRN/BLU WIRE GRY/VIO WIRE LEFT INNER TAILLIGHT LEFT OUTER TAILLIGHT REVERSING LIGHT RIGHT OUTER TAILLIGHT TAIL LAMP TRAILER MODULE TRAILER SOCKET PREPARATION TURN SIGNAL/ DYNAMIC BRAKE LIGHT W/ TRAILER MODULE W/O TRAILER MODULE WHT WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE
