BMW X7 G07 (2018-2022) Anti-theft & central locking circuit

BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/RED WIRE BLU/GRN WIRE BLU/GRY WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CENTRAL LOCKING BUTTON DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S DOOR SWITCH BLOCK FUSE 244 FUSE 254 FUSE 504 FUSE 67 FUSE BOX GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HOOD CONTACT SWITCH HORNS SYSTEM HOT AT ALL TIMES HOT W/ TERMINAL NUMBER PLATE LIGHT W/ REAR LID BUTTON ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/BRN WIRE RED/GRN WIRE REMOTE CONTROL RECEIVER RIGHT FRONT POWER DISTRIBUTION BOX VEHICLE INTERIOR TAILGATE BUTTON VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE YEL/GRN WIRE

ANTI- THEFT ALARM LED BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/RED WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DEADLOCKING DRIVE DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE DRIVER'S DOOR LOCK ELECTROCHROMIC INTERIOR MIRROR FUEL FILLER FLAP CENTRAL LOCKING DRIVE GRN WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE LUGGAGE COMPARTMENT LIGHT ORG/ WIRE ORG/GRN WIRE RED WIRE RED/GRN WIRE RED/YEL WIRE ROOF FUNCTION CENTER ROTARY STRIKER SWITCH HALL EFFECT SENSOR SIREN W/ TILT ALARM SENSOR TRUNK LID TAILGATE BUTTON UNLOCKING, LOCKING MECHANISM DRIVE VIO WIRE VIO/BLU WIRE VIO/GRY WIRE W/ AUTOMATIC SOFT CLOSE SYSTEM W/O AUTOMATIC SOFT CLOSE SYSTEM WHT/BRN WIRE WHT/GRY WIRE YEL WIRE YEL/GRN WIRE

BLK/BRN WIRE BLK/GRY WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS FRONT PASSENGER'S DOOR CENTRAL LOCKING BUTTON FRONT PASSENGER'S DOOR POWER WINDOW SWITCH FUSE 249 FUSE 251 FUSE 254 FUSE 264 GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT W/ TERMINAL LOWER TRUNK LID TAILGATE BUTTON NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE TAILGATE LOCK TRUNK LID POWERTRAIN AUTOMATIC SOFT CLOSE SYSTEM VIO/GRY WIRE WHT/BRN WIRE WHT/GRY WIRE YEL/GRN WIRE

BLK/BRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE DEADLOCKING DRIVE FRONT PASSENGER DOOR LOCK FRONT PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE SYSTEM DRIVE UNIT GRY WIRE GRY/YEL WIRE LEFT LOWER TRUNK LID LOCK LEFT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID ORG/ WIRE RED/GRN WIRE RIGHT SOFT-CLOSE AUTOMATIC LOWER TRUNK LID ROTARY STRIKER SWITCH HALL EFFECT SENSOR UNLOCKING, LOCKING MECHANISM DRIVE VIO WIRE VIO/GRY WIRE W/ AUTOMATIC SOFT CLOSE SYSTEM W/O AUTOMATIC SOFT CLOSE SYSTEM WHT/BRN WIRE WHT/GRY WIRE YEL WIRE YEL/GRN WIRE

BLK/GRY WIRE BLU/GRN WIRE BLU/GRY WIRE BRN WIRE BRN/YEL WIRE DEADLOCKING DRIVE FUSE 256 FUSE 258 GRN WIRE GRY/YEL WIRE HOT W/ TERMINAL POWER DISTRIBUTION SYSTEM REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR DRIVERS SIDE DOOR LOCK REAR PASSENGER'S SIDE AUTOMATIC SOFT CLOSE SYSTEM DRIVE REAR PASSENGER'S SIDE DOOR LOCK REAR POWER DISTRIBUTION BOX RED/GRY WIRE RED/VIO WIRE RIGHT LOWER TRUNK LID LOCK ROTARY STRIKER SWITCH HALL EFFECT SENSOR UNLOCKING, LOCKING MECHANISM DRIVE VIO/GRY WIRE W/ AUTOMATIC SOFT CLOSE SYSTEM W/ ELECTRIC ROLLER SUNBLINDS W/O AUTOMATIC SOFT CLOSE SYSTEM WHT/BRN WIRE WHT/GRN WIRE YEL WIRE
