Parking assistant circuit, w/o parking maneuvering assistant & surround view camera for BMW X6 G06 facelift (2023-2024)
Parking assistant circuit, w/o parking maneuvering assistant & surround view camera (1 of 2)
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/YEL WIRE
FUSE 71
GRN/GRY WIRE
GRN/RED WIRE
HOT W/
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT OUTER ULTRASONIC SENSOR
LEFT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
ORG/ WIRE
ORG/GRN WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT OUTER ULTRASONIC SENSOR
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
ULTRASONIC SENSOR CONTROL UNIT (USS)
YEL/BRN WIRE
YEL/GRY WIRE
Parking assistant circuit, w/o parking maneuvering assistant & surround view camera (2 of 2)
BRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
CENTER CONSOLE CONTROL
COMPUTER DATA LINES SYSTEM
FUSE 32
GRN/GRY WIRE
HOT AT ALL TIMES
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR OUTER ULTRASONIC SENSOR
LEFT REAR ULTRASONIC SENSOR
ORG/ WIRE
ORG/GRN WIRE
PARKING ASSISTANCE BUTTON
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR OUTER ULTRASONIC SENSOR
RIGHT REAR ULTRASONIC SENSOR
WHT/BLU WIRE
WHT/YEL WIRE
YEL/BRN WIRE
