BMW X6 G06 facelift (2023-2024) wastegate valve controller 2 Wiring diagram
This page shows the only wiring diagram for the component.wastegate valve controller 2, which is found in the car BMW X6 G06 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wastegate valve controller 2 (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CONTROLLED INJECTION SOLENOID VALVE CYLINDER 5
CONTROLLED INJECTION SOLENOID VALVE CYLINDER 6
CONTROLLED INJECTION SOLENOID VALVE CYLINDER 7
CONTROLLED INJECTION SOLENOID VALVE CYLINDER 8
GRN WIRE
RED WIRE
WASTEGATE VALVE CONTROLLER 2
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.4l turbo (9 of 11) -> WASTEGATE VALVE CONTROLLER 2
