Awd circuit for BMW X6 E71 facelift (2012-2014)
Awd circuit
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CLASSIFICATION RESISTOR (ON TRANSFER CASE ACTUATOR MOTOR)
COMPUTER DATA LINES SYSTEM
FUSE 125
FUSE 92
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
NCA WIRE
REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
TRANSFER BOX CONTROL MODULE (LEFT REAR CARGO AREA)
VIO WIRE
VTG ACTUATOR
WHT WIRE
YEL WIRE
