3.0l turbo, a/t circuit for BMW X6 E71 facelift (2012-2014)
3.0l turbo, a/t circuit
30 41 BUS SIG SIG
ANTI-THEFT SYSTEM
BLK/BLU WIRE
BLU/RED WIRE
BRN WIRE
CAR ACCESS SYSTEM CONTROL MODULE (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE 13
GEAR SELECTOR SWITCH
GRN/RED WIRE
GRY WIRE
JUNCTION BOX FUSE 15 (UNDER RIGHT SIDE OF DASH)
PA BUS SIG SIG
PT CAN HIGH PT CAN LOW
RED WIRE
RED/YEL WIRE
RELAY ENERGIZED
SIG PARKED POS
SUPP,TER 30 GND
TRANSMISSION CONTROL (IN TRANSMISSION)
VIO WIRE
W/ COMFORT ACCESS W/O COMFORT ACCESS
WAKE UP SIG
WHT WIRE
YEL WIRE
YEL/GRN WIRE
