Driver"s memory seat circuit, without lumbar support for BMW X6 E71 facelift (2012-2014)
Driver"s memory seat circuit, without lumbar support (1 of 2)
BLK/YEL WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE
DRIVER'S SEAT DEPTH ADJUSTMENT MOTOR (W/ COMFORT SEAT)
DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE
DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE
DRIVER'S SEAT MODULE
GRN WIRE
GRN/BLK WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
ORG/GRN WIRE
RED/BRN WIRE
SEATS SYSTEM
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
WHT/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Driver"s memory seat circuit, without lumbar support (2 of 2)
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT DRIVE
DRIVER'S SEAT BACKREST HEAD ADJUSTMENT MOTOR (W/ COMFORT SEAT)
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT MOTOR (W/ COMFORT SEAT)
DRIVER'S SEAT HEAD RESTRAINT ADJUSTMENT DRIVE
DRIVER'S SEAT MODULE
FUSE
GRY/GRN WIRE
GRY/WHT WIRE
NCA WIRE
REAR POWER DISTRIBUTION BOX
RED/BRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
SEATS SYSTEM
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
