Anti-theft & central locking circuit for BMW X6 E71 facelift (2012-2014)

45 46 K - BUS SIG L K - BUS SIG H ANTI-THEFT ALARM SYSTEM LED BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/GRY/YEL WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SYSTEM LOCK ELECTRO- CHROMIC REAR VIEW MIRROR ELECTRONICS JUNCTION BOX FOOTWELL MODULE (LEFT KICK PANEL) FUEL FILLER FLAP CENTRAL LOCKING DRIVE (RIGHT REAR QUARTERPANEL) FUSE GLOVE COMPARTMENT BUTTON GRN WIRE GRY WIRE GRY/BLK/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES JUNCTION BOX (UNDER FUSE RIGHT SIDE OF DASH) LEFT REAR SYSTEM LOCK (IN LEFT REAR DOOR) ORG/GRN WIRE PASSENGER'S DOOR SYSTEM LOCK RED WIRE RED/BRN WIRE RED/VIO WIRE RELAY ENERGIZED ROOF FUNCTION CONTROL CENTER SIREN, TILT ALARM SENSOR TRUNK LID/TAILGATE AUTOMATIC SOFT-CLOSE DRIVE (CENTER REAR OF LUGGAGE COMPT) TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE WHT/BLK WIRE YEL/BLK WIRE

ANTENNA REMOTE DIVERSITY CONTROL (TOP CENTER RECEIVER OF LIFTGATE) BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BOOT LID BUTTON BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CAN L CAR ACCESS SYSTEM CONTROL MODULE (LEFT END OF DASH) COMPUTER DATA LINES SYSTEM CTRL LCK SIG DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE FUSE GLOVE COMPARTMENT LIGHT GLOVE COMPARTMENT UNLOCK DRIVE UNIT GRN WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING SWITCH HOOD CONTACT SWITCH (RIGHT FRONT OF ENGINE COMPT) LEFT REAR AUTOMATIC SOFT-CLOSE DRIVE LID CONT SIG NOISE SUPPRESSOR FILTER ORG/GRN WIRE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE REAR PASSENGER'S SIDE SYSTEM LOCK (IN REAR PASSENGER'S DOOR) REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL) RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED REM CTRL REC RIGHT REAR AUTOMATIC SOFT-CLOSE DRIVE SEAT) TRUNK LID CENTRAL LOCKING DRIVE VIO/GRN WIRE W/ INTERFERENCE SUPPRESSION FILTER W/O INTERFERENCE SUPPRESSION FILTER WHT WIRE YEL/RED WIRE
