BMW X6 E71 facelift (2012-2014) right actuator motor Wiring diagrams
This page contains all the electrical diagrams for the component. right actuator motor, in which he is found in the car BMW X6 E71 facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right actuator motor (1 of 3)
ACTIVE STEERING (UNDER REAR OF
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 123
GRN/RED WIRE
HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX FUSE 93 (RIGHT REAR QUARTER PANEL)
HOT W/ TERMINAL
LEFT ACTUATOR MOTOR
LEFT FRONT FENDER)
LEFT MOTOR POSITION SENSOR
LEFT OIL TEMPERATURE SENSOR
NCA WIRE
ORG/ WIRE
REAR AXLE TRANSVERSE TORQUE DISTRIBUTION (QMVH)
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RIGHT ACTUATOR MOTOR
RIGHT MOTOR POSITION SENSOR
RIGHT OIL TEMPERATURE SENSOR
W/ ACTIVE STEERING
W/O ACTIVE STEERING
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> 3.0l turbo, rear axle circuit -> RIGHT ACTUATOR MOTOR
Wiring diagram right actuator motor (2 of 3)
ACTIVE STEERING (UNDER REAR OF
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 123
GRN/RED WIRE
HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX FUSE 93 (RIGHT REAR QUARTER PANEL)
HOT W/ TERMINAL
LEFT ACTUATOR MOTOR
LEFT FRONT FENDER)
LEFT MOTOR POSITION SENSOR
LEFT OIL TEMPERATURE SENSOR
NCA WIRE
ORG/ WIRE
REAR AXLE TRANSVERSE TORQUE DISTRIBUTION (QMVH)
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RIGHT ACTUATOR MOTOR
RIGHT MOTOR POSITION SENSOR
RIGHT OIL TEMPERATURE SENSOR
W/ ACTIVE STEERING
W/O ACTIVE STEERING
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> 4.4l twin turbo, rear axle circuit -> RIGHT ACTUATOR MOTOR
Wiring diagram right actuator motor (3 of 3)
ACTIVE STEERING (UNDER REAR OF
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 123
GRN/RED WIRE
HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX FUSE 93 (RIGHT REAR QUARTER PANEL)
HOT W/ TERMINAL
LEFT ACTUATOR MOTOR
LEFT FRONT FENDER)
LEFT MOTOR POSITION SENSOR
LEFT OIL TEMPERATURE SENSOR
NCA WIRE
ORG/ WIRE
REAR AXLE TRANSVERSE TORQUE DISTRIBUTION (QMVH)
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RIGHT ACTUATOR MOTOR
RIGHT MOTOR POSITION SENSOR
RIGHT OIL TEMPERATURE SENSOR
W/ ACTIVE STEERING
W/O ACTIVE STEERING
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Rear axle circuit -> RIGHT ACTUATOR MOTOR
