BMW X6 E71 facelift (2012-2014) power power distribution distribution system system Wiring diagram
This page shows the only wiring diagram for the component.power power distribution distribution system system, which is found in the car BMW X6 E71 facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power power distribution distribution system system (1 of 1)
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FOOTWELL MODULE (LEFT KICK PANEL)
FUSE
FUSE 19
GRN WIRE
GRN/WHT WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ TERMINAL 15 RELAY ENERGIZED
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
POWER POWER DISTRIBUTION DISTRIBUTION SYSTEM SYSTEM
REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
ROOF FUNCTION CONTROL CENTER
SIG SW
SLIDE/TILT SUNROOF DRIVE UNIT
W/ SUNROOF
W/O SIG
W/O SUNROOF
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Power top/sunroof circuit -> POWER POWER DISTRIBUTION DISTRIBUTION SYSTEM SYSTEM
