BMW X6 E71 facelift (2012-2014) left ventilation flap motor Wiring diagrams
This page contains all the electrical diagrams for the component. left ventilation flap motor, in which he is found in the car BMW X6 E71 facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left ventilation flap motor (1 of 2)
1 2 3 4 5 6 7 8 9 10 STPPR GND L TEMP EXCHG LIN BUS
BACK PRESSURE FLAP MOTOR
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE SWITCH
DEFROSTER FLAP MOTOR
EVAPORATOR TEMPERATURE SENSOR
FRESH AIR/ RECIRCULATING AIR FLAP MOTOR (ON HVAC UNIT)
GND EVA TEMP SNS R TEMP EXCHG
GRN/RED WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT W/ DME MAIN RELAY ENERGIZED CURRENT DISTRIBUTOR FUSE
LEFT FOOTWELL FLAP MOTOR
LEFT FRONT STRATIFYING AIR FLAP MOTOR
LEFT HEATING HEAT EXCHANGER TEMPERATURE SENSOR
LEFT VENTILATION FLAP MOTOR
MAP THERMOSTAT (RIGHT FRONT OF ENGINE)
NCA WIRE
ORG/ WIRE
RADIATOR SHUTTER DRIVER (3.0L TWIN TURBO) (BEHIND CENTER OF FRONT FASCIA)
REAR COMPARTMENT MIXING FLAP MOTOR
RED/BLU WIRE
RED/GRN WIRE
RIGHT FOOTWELL FLAP MOTOR (ON HVAC UNIT)
RIGHT HEATING HEAT EXCHANGER TEMPERATURE SENSOR
RIGHT REAR STRATIFYING AIR FLAP MOTOR
RIGHT VENTILATION FLAP MOTOR
STPPR PWR
WHT/RED WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit, except basic without rear compartment blower (4 of 4) -> LEFT VENTILATION FLAP MOTOR
Wiring diagram left ventilation flap motor (2 of 2)
1 2 3 4 5 6 7 8 9 10 STPPR GND L TEMP EXCHG LIN BUS
BACK PRESSURE FLAP MOTOR
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE SWITCH
DEFROSTER FLAP MOTOR (ON HVAC UNIT)
EVAPORATOR TEMPERATURE SENSOR
FRESH AIR/RECIRCULATING AIR FLAP MOTOR (ON HVAC UNIT)
GND EVA TEMP SNS R TEMP EXCHG
GRN WIRE
GRN/RED WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT W/ DME MAIN RELAY ENERGIZED CURRENT DISTRIBUTOR FUSE
LEFT FOOTWELL FLAP MOTOR (ON HVAC UNIT)
LEFT FRONT STRATIFYING AIR FLAP MOTOR
LEFT HEATING HEAT EXCHANGER TEMPERATURE SENSOR
LEFT REAR CABIN FOOTWELL FLAP MOTOR (ON HVAC UNIT)
LEFT REAR STRATIFYING AIR FLAP MOTOR
LEFT VENTILATION FLAP MOTOR
MAP THERMOSTAT (RIGHT FRONT OF ENGINE)
NCA WIRE
ORG/ WIRE
RADIATOR SHUTTER DRIVER (3.0L TWIN TURBO) (BEHIND CENTER OF FRONT FASCIA)
RED/BLU WIRE
RED/GRN WIRE
RIGHT FOOTWELL FLAP MOTOR (ON HVAC UNIT)
RIGHT HEATING HEAT EXCHANGER TEMPERATURE SENSOR
RIGHT REAR FOOTWELL FLAP MOTOR
RIGHT REAR RIGHT FRONT STRATIFYING STRATIFYING AIR FLAP MOTOR AIR FLAP MOTOR
RIGHT VENTILATION FLAP MOTOR
STPPR PWR
WHT/RED WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit, except basic with rear compartment blower (4 of 4) -> LEFT VENTILATION FLAP MOTOR
