BMW X6 E71 facelift (2012-2014) headset satellite connection receiver module Wiring diagram
This page shows the only wiring diagram for the component.headset satellite connection receiver module, which is found in the car BMW X6 E71 facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headset satellite connection receiver module (1 of 1)
ACTIVE CRUISE CONTROL
ACTIVE VIDEO SWITCH
AERIAL DIVERSITY
AUC SENSOR
BLK WIRE
BRAKE DSC LIGHT SENSOR SWITCH
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/BLK WIRE
CAR ACCESS SYSTEM
CENTRAL VIDEO INFORMATION MODULE DISPLAY
COMBOX
COOLANT LEVEL SWITCH
CRASH SAFETY MODULE
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE CONTACT
DRIVER'S SEAT MODULE
DRIVER'S SEAT OCCUPANCY ELECTRONICS
DVD HEAD-UP CHANGER DISPLAY
EJECT BOX
FOOTWELL MODULE
HEADSET SATELLITE CONNECTION RECEIVER MODULE
HIFI AMPLIFIER
HOOD CONTACT SWITCH
INSTRUMENT CLUSTER CONTROL UNIT
INTEGRATED CHASSIS MANAGEMENT (ICM)
LEFT HEAD- LIGHT
LONGITUDINAL DYNAMICS MANAGEMENT
NCA WIRE
OBDII SOCKET
PARK DISTANCE CONTROL
PASSENGER'S SEAT BELT BUCKLE CONTACT
PASSENGER'S SEAT OCCUPANCY DETECTION
REAR COMPARTMENT DISPLAY
REAR SEAT CD ENTER- CHANGER TAINMENT
RIGHT HEAD- LIGHT
SHIELD
STEERING COLUMN SWITCH CLUSTER
TCU
TIRE PRESSURE CONTROL
TRUNK LID LIFT
ULF- USB HUB SBX-H
ULF-SBX
ULF-SBX-H INTERFACE BOX HIGH
W/ COMBOX
W/ TCU
W/ ULF SBX INTERFACE BOX
Go to component -> Ground distribution circuit (3 of 5) -> HEADSET SATELLITE CONNECTION RECEIVER MODULE
