BMW X6 E71 facelift (2012-2014) fuse 173 Wiring diagram
This page shows the only wiring diagram for the component.fuse 173, which is found in the car BMW X6 E71 facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 173 (1 of 1)
7 17 CAN BUS LO CAN BUS HI
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 173
FUSE BOX
GRN WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
ORG/GRN WIRE
REAR WINDOW DEFOGGER
REAR WINDOW HEATED RELAY
RED WIRE
WAVE TRAP 2
WAVE TRAP 3
Go to component -> Rear defogger circuit -> FUSE 173
