BMW X6 E71 facelift (2012-2014) car information computer Wiring diagram
This page shows the only wiring diagram for the component.car information computer, which is found in the car BMW X6 E71 facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram car information computer (1 of 1)
ALL ROUND VISION CAMERA (LEFT SIDE OF DASH)
BLU WIRE
BRN WIRE
CAR INFORMATION COMPUTER
COMPUTER DATA LINES SYSTEM
FUSE 114 DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
GRN WIRE
GRN/WHT WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT BUMPER CAMERA
LEFT EXTERIOR MIRROR CAMERA (IN LEFT REAR VIEW MIRROR ASSEMBLY)
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
REAR POWER
RED/GRN WIRE
REVERSING CAMERA (RIGHT SIDE OF REAR LID)
RIGHT BUMPER CAMERA
RIGHT EXTERIOR MIRROR CAMERA (IN RIGHT REAR VIEW MIRROR ASSEMBLY)
W/O MMC W/ MMC
WHT WIRE
Go to component -> All around vision camera circuit -> CAR INFORMATION COMPUTER
