BMW X6 E71 facelift (2012-2014) automatic trunk lid interior boot lid button Wiring diagram
This page shows the only wiring diagram for the component.automatic trunk lid interior boot lid button, which is found in the car BMW X6 E71 facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic trunk lid interior boot lid button (1 of 1)
AUTO- MATIC SOFT- CLOSE RELAY
AUTOMATIC TRUNK LID INTERIOR BOOT LID BUTTON
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUNCTION BOX
FUEL FILLER FLAP CENTRAL LOCKING DRIVE (RIGHT REAR QUARTER PANEL)
FUSE
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
HOT W/
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT BOOT LID RIGHT BOOT LID LIFT DRIVE UNIT LIFT DRIVE UNIT
NCA WIRE
NOISE SUPPRESSOR FILTER
ORG/GRN WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
TRUNK LID BUTTON
TRUNK LID LIFT (RIGHT REAR QUARTER PANEL)
TRUNK LID/TAILGATE AUTOMATIC TRUNK LID CENTRAL SOFT-CLOSE DRIVE LOCKING DRIVE
W/ INTERFERENCE SUPPRESSION FILTER
W/O INTERFERENCE SUPPRESSION FILTER
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Trunk & fuel door release circuit -> AUTOMATIC TRUNK LID INTERIOR BOOT LID BUTTON
