Car Wiring Diagrams for Awd circuit for BMW X6 E71 (2007-2012)

BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE CLASSIFICATION RESISTOR (ON TRANSFER CASE ACTUATOR MOTOR) COMPUTER DATA LINES SYSTEM ENERGIZED REAR POWER DISTRIBUTION BOX FUSE (RIGHT REAR QUARTER PANEL) FUSE GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL NCA WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE TRANSFER BOX CONTROL MODULE (LEFT REAR CARGO AREA) VIO WIRE VTG ACTUATOR (ON TRANSFER CASE) WHT WIRE YEL WIRE
