Hifi radio circuit, with ccc & m-ask for BMW X6 E71 (2007-2012)

Hifi radio circuit, with ccc & m-ask (1 of 3)

X6 BMW E71 (2007-2012): Hifi radio circuit, with ccc & m-ask (1 of 3)

Get access

1 2 3 4 5 (PINS: 6-12 NOT USED) ANTENNA DIVERSITY (TOP CENTER OF REAR COMPT) ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CCC/M-ASK COMPUTER DATA LINES SYSTEM DIGITAL TUNER US FUSE FUSE GRN WIRE GRY WIRE GRY/RED WIRE NAVIGATION SYSTEM (OUTSIDE MIRROR CAMERA CIRCUIT) NCA WIRE ORG/ WIRE ORG/GRN WIRE REAR CAMERA CIRCUIT REAR SPOILER AERIAL REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RELAY ENERGIZED RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) FUSE RTTI SPLITTER SOUND SYSTEMS (REAR SEAT ENTERTAINMENT CIRCUIT) WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

Hifi radio circuit, with ccc & m-ask (2 of 3)

X6 BMW E71 (2007-2012): Hifi radio circuit, with ccc & m-ask (2 of 3)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE CD CHANGER DVD CHANGER GRN WIRE GRY/RED WIRE HEAD-UP DISPLAY LEFT REAR HIGH RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER MOST-BUS CONNECTOR NCA WIRE RED WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RIGHT FRONT SUBWOOFER ROOF AERIAL SATELLITE RECEIVER VIDEO SELECTOR SWITCH W/ DVD CHANGER W/ CD CHANGER W/O REVERSING CAMERA W/ REVERSING CAMERA 2 3 4 WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Hifi radio circuit, with ccc & m-ask (3 of 3)

X6 BMW E71 (2007-2012): Hifi radio circuit, with ccc & m-ask (3 of 3)

Get access

BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM GRN WIRE HIFI AMPLIFIER LEFT FRONT MID-RANGE SPEAKER LEFT FRONT SUBWOOFER LEFT FRONT TWEETER LEFT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK NCA WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HIGH RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH BLOCK STEERING COLUMN SWITCH CLUSTER TOP CENTER INSTRUMENT PANEL SPEAKER TWEETER WHT/BLU WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
