Power windows circuit for BMW X6 E71 (2007-2012)
Power windows circuit
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S POWER WINDOW MOTOR
FOOTWELL MODULE
FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
LEFT REAR POWER WINDOW MOTOR
ORG/GRN WIRE
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S POWER WINDOW MOTOR
REAR DRIVER'S SIDE POWER WINDOW SWITCH
REAR PASSENGER'S SIDE POWER WINDOW SWITCH
RED WIRE
RED/GRN WIRE
RIGHT REAR POWER
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
WINDOW MOTOR
