Power top/sunroof circuit for BMW X6 E71 (2007-2012)
Power top/sunroof circuit
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM
FOOTWELL MODULE
FUSE
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ TERMINAL 15 RELAY ENERGIZED
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
RED/BLU WIRE
RED/BRN WIRE
RELAY ENERGIZED
ROOF FUNCTION CONTROL CENTER
VISOR MOTOR (CENTER REAR OF ROOF)
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/WHT WIRE
