Seat ventilation circuit for BMW X6 E71 (2007-2012)

Seat ventilation circuit (1 of 2)

X6 BMW E71 (2007-2012): Seat ventilation circuit (1 of 2)

Get access

BLK WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST FAN 1 DRIVER'S SEAT BACKREST FAN 2 DRIVER'S SEAT BACKREST FAN 3 DRIVER'S SEAT BACKREST FAN 4 DRIVER'S SEAT CUSHION FAN 1 DRIVER'S SEAT CUSHION FAN 2 DRIVER'S SEAT CUSHION FAN 3 DRIVER'S SEAT CUSHION FAN 4 DRIVER'S SEAT CUSHION FAN 5 DRIVER'S SEAT MODULE GRN WIRE HOT W/ ORG/GRN WIRE RED/BRN WIRE RELAY ENERGIZED REAR POWER DISTRIBUTION BOX FUSE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

Seat ventilation circuit (2 of 2)

X6 BMW E71 (2007-2012): Seat ventilation circuit (2 of 2)

Get access

BLK WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GRN WIRE HOT W/ ORG/GRN WIRE PASSENGER'S SEAT BACKREST FAN 1 PASSENGER'S SEAT BACKREST FAN 2 PASSENGER'S SEAT BACKREST FAN 3 PASSENGER'S SEAT BACKREST FAN 4 PASSENGER'S SEAT CUSHION FAN 1 PASSENGER'S SEAT CUSHION FAN 2 PASSENGER'S SEAT CUSHION FAN 3 PASSENGER'S SEAT CUSHION FAN 4 PASSENGER'S SEAT CUSHION FAN 5 PASSENGER'S SEAT MODULE RED/GRN WIRE RELAY ENERGIZED REAR POWER DISTRIBUTION BOX FUSE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE
